    Ditch Lining Concrete Impregnated Canvas GCCM Rolls

    Ask Lasest Price
    Brand Name : PIONEERTEX
    Model Number : CEMENT CANVAS
    Supply Ability : 1000 Square Meter/Square Meters per Week
    Price : $2.40 - $2.95 / Square Meter
    Certification : ISO9001 and ISO14001
    • Product Details
    • Company Profile

    Ditch Lining Concrete Impregnated Canvas GCCM Rolls

    Cement Canvas(Concrete Impregnated Canvas) GCCM is a flexible and soft cement impregnated fabric, that hardens on hydration to form a thin,durable,water proof and fire retardant concrete layer. Essentially, it's .

    Cement Canvas GCCM allows concrete construction without the need for plant or mixing equipment. It's very easy, and just add water on the CC top face-canvas side.

    Cement Canvas GCCM was made of 3D spacer fabric and Glass roving woven geotextile or HDPE geo-membrane. The specially formulated dry concrete powder mix will be reinforced by 3D spacer fabric in the middle, and covered by glass roving geotextile or water-proof HDPE geo-membrane.

    Once set, the 3D spacer fabric will reinforce the concrete, prevent crack propagation and provide a safe plastic failure mode. The glass roving at the bottom will offer special protection on the CC, and offer higher tensile strength for composite.

    HDPE geo-membrane backing at the bottom face of CC ensures the material is completely water proof. Cement Canvas GCCM is available in 4 thickness CC5, CC8, CC10 and CC13, which are 5,8,10 and 13mm thick respectively.

    ITEMTEST METHOD5MM8MM13MM
    Flexural Strength (Final)ASTM D80584.0MPa4.0MPa4.0MPa
    Compressive StrengthASTM D832940Mpa50Mpa60Mpa
    Tensile Strength(unset)ASTM D67688KN/M
    Tensile Strength(set-final)ASTM D488520KN/M25KN/M30KN/M
    Abasion(Max.value)ASTM C13530.3MM/1000 cycles
    REMARK: CC10 data sheet is between 8mm and 13mm.
