    Glass Filament Composite Geogrid For Surface Course Reinforcement

    Ask Lasest Price
    Brand Name : PIONEERTEX
    Model Number : Comobogrid
    Supply Ability : 50000 Square Meter/Square Meters per Month
    Price : $0.90 - $1.80 / Square Meter
    Certification : ISO9001 and ISO14001
    Delivery Time : 2-3weeks
    • Product Details
    • Company Profile

    Glass Filament Composite Geogrid For Surface Course Reinforcement

    Combogrid-Glass Filament Geogrid Reinforced Needle Punch Nonwoven Geotextile Geocomposite Pavement Reinforcement System


    PioneerTex Glass Geogrid and Nonwoven Geotextile Composite-Polypave Combogrid


    Glass Filament Reinforced Nonwoven Paving Mat Geocomposite Coated Bitumen for Asphalt Overlay Reinforcement


    Instruction:


    PioneerTex Glass Filament Reinforced Nonwoven Paving Mat is an asphalt reinforcement composite which combines a high tensile E type Fiberglass grid with a lightweight non-woven by warp-knitting processing. Then both of them coated with modified bitumen to strengthen the bond with the asphalt layers.


    This glass-polypave composite provides excellent performance in stress relief and to prevent reflective cracking in asphalt overlays. PioneerTex glass filament reinforced nonwoven paving mat geo-composite provides significantly greater tensile strength at low strain when compared to the conventional paving fabric and mats, which reduces maintenance costs by delaying reflective cracking and extends the service life of the overlay.

    Applications:

    Surface course reinforcement

    Cracks prevention and road maintanance and repair

    Asphalt or Concrete road resurfacing

    Airport Construction


    Features:

    High-strength, low elongation

    High asphalt absorption / retention

    Good separation against moisture and gases to road base.

    Better bonding strength with surface layers.

    Easy installation and save labor cost.


    Hybrid Pavement Reinforcement Interlay System
    Glass Filament Reinforced Needle Punch Nonwoven Geotextile Composite
    Technical Specification
    PropertiesUnitGC-30/30GC-50/50GC-100/100GC-120/120
    Materials/Glass Filament + PET Needle Punch Nonwoven Geotex
    Nonwoven/120gsm Polyester Needle Punch Nonwoven
    Coating/non-coating
    Mesh size of Gridmm25.4 x 25.4
    Ultimate Tensile StrengthKN/M30 x 3050 x 50100 x 100120 x 120
    MD x CMD
    Elongation at Ultimate%<3<3<3<3
    Roll WidthM5.95 Max.
    Roll LengthM50 - 100

    Glass Filament Composite Geogrid For Surface Course ReinforcementGlass Filament Composite Geogrid For Surface Course Reinforcement


    Glass Filament Composite Geogrid For Surface Course Reinforcement


    Glass Filament Composite Geogrid For Surface Course Reinforcement


    Quality Glass Filament Composite Geogrid For Surface Course Reinforcement for sale
