    100-1000KN/M PET High Strength Woven Geotextile for soft soil reinforcement

    Ask Lasest Price
    Brand Name : pioneertex
    Model Number : HS PET
    Certification : ISO9001 and ISO14001
    Price : $1.85 - $5.85 / Square Meter
    Payment Terms : T/T, L/C
    Supply Ability : 30000 Square Meter/Square Meters per Month
    Delivery Time : 2-3weeks
    MOQ : 2000 sqm
    • Product Details
    • Company Profile

    100-1000KN/M PET High Strength Woven Geotextile for soft soil reinforcement

    High strength PET Multifilament woven geotextile from PioneerTEX CHINA.



    Who are we?


    We, PioneerTEX is a professional manufacturer of geotube and geobag in China.

    We could produce many types of geotube and geobag as per customer's project request.

    All bags and fabrics could be customized.


    What is HS PET Woven Geotextile?


    PioneerTEX® HS PET Woven geotextiles are polymer based GEOTEX that are manufactured specifically for applications of soft soil reinforcement. PioneerTEX® woven geotextiles are manufactured from the extrusion of a polymer (polypropylene or polyester) into either a flat tape or filament product which may be then further processed by slitting or bundling and then weaving to form a fabric.


    Application of HS PET Woven Geotextile:


    1. High strength reinforcement for soft soil such as under embankments.

    2. Separation for soft soil, work with geocell for soft soil separation and filtration;

    3. Proven for use in Main Roads works


    PioneerTEX HS Woven Geotextile Advantage:


    1. HIgh strength up to 1200KN/M;

    2. Low elonagation at break means very low creepy under loading;

    3. Long life span more than 30 years.

    4. Quality certified

    5. Large range to suit the application

    6. Wide-width rolls: 3.8M.


    PioneerTEX PET HS Woven Geotextile Technical Data Sheet


    PioneerTEX High Strength PET Woven Geotextile
    PropertyTest MethodUnitsHS100HS200HS300HS400HS600HS800HS1000HS1300
    Wide Width Tensile Strength
    MD @ UltimateASTM D4595KN/m10020030040060080010001300
    CD @ UltimateASTM D4595KN/m10050505050505050
    Elongation @ Ultimate
    MD @ UltimatdeASTM D4595%12%
    WEIGHTN/AG/M23504306107801120147018202350

    Packaging
    Roll WidthN/Am5.2 mts
    Roll LengthN/Am100mts/Roll


    PioneerTEX HD PET Woven Geotextile Workshop
