30-30KN/M Needle Punch Nonwoven Geotextile Big Silt Big Or Small Geo Bags For Slope Protection

PIONEERTEX NONWOVEN GEOTEXTILE SILT BAG:

30-30KN/M Needle Punch Nonwoven Geotextile Big Silt Big Or Small Geo Bags For Slope Protection

PioneerTEX Filter Silt Bags were manufacturered from a heavy-weight, UV resistant, needle punch nonwoven geotextile or PET nonwoven and High Strength Woven Geotextile Composite sew into a large, completely enclosed bag. And the FilterBags are fabricated with a "J" seam.

Customized geobags are available upon request, especially the filter material such as Nonwoven geotextile, Woven Geotextile, Nonwoven and Woven geotextile composite.PioneerTEX Silt bags could be made to order, and are available upon request.

PioneerTEX Dewatering Silt Bags Material Properties

-PP Staple Fiber Needle Punch Nonwoven Geotextile

PioneerTEX GEOBAG	PP STAPLE FIBER NEEDLE PUNCH NONWOVEN GEOTEXTILE FOR SILT BAGS
Fabric Style	ASTM	PT 6	PT 8	PT 10
AOS, Sieve (Microns)	D4751	70 (212)	80 (180)	100 (150)
Water Flow	D4491	110 gpm/ft^{2 4,480 l/min/m2}	90 gpm/ft^{2 3,657 l/min/m2}	80 gpm/ft^{2 3,251 l/min/m2}
Grab Tensile	D4632	160 lbs 711 N	205 lbs 911 N	250 lbs 1,110 N
Elongation	D4632	50 %	50 %	50 %
Tear	D4533	60 lbs 267 N	80 lbs 356 N	99.8 lbs 444 N
CBR Puncture	D6241	410 lbs 1820 N	523 lbs 2330 N	649 lbs 2890 N
Note: PT6, PT8, and PT10 are non-woven needle punched geotextiles. For other available styles of non-woven needle punched geotextiles please see PIONEERTEX Geotextiles section. Higher strength of Nonwoven or composite are available upon request.

30-30KN/M Needle Punch Nonwoven Geotextile Big Silt Big Or Small Geo Bags For Slope Protection

PioneerTEX PP Nonwoven Geotextile Silt Bags Specification

Color	Black or Green
Material	100% Polypropylene
Size	3' x 4' / 6' x 6' / 10' x 15' / 15' x 15'
Weight	270gsm
Width	91.5cm / 183cm / 305cm / 457cm
Process	Lustring PP fabric, Sewing, Packing
Application	Contain sediment and oil pumped out during dewatering operations
Place of origin	Jiangsu, Mainland China

30-30KN/M Needle Punch Nonwoven Geotextile Big Silt Big Or Small Geo Bags For Slope Protection

PET Filament Needle Punch Nonwoven Geotextile for Silt Bags:

MECHANICAL PROTERTIES	UNIT	GTX 110	GTX 125	GTX 150	GTX 200	GTX 250	GTX 300	GTX 350	GTX 400	GTX 450	GTX 500	GTX 550	GTX 600
TENSILE STRENGTH T	KN/M	4.5	7	9	10.5	14	17	21	24	25	27	29	31
[ASTM D 4595] M	KN/M	4.5	5.5	7.5	8.5	12	15	18	20	22	24	27	29
ELONGATION AT BREAK T	%	80	80	70	60	60	60	60	60	60	60	60	60
[ASTM D 4595] M	%	50	50	50	50	50	50	50	50	50	50	50	50
GRAB STRENGTH T	N	300	400	550	600	850	1000	1250	1450	1700	1900	2100	2300
[ASTM D 4632] M	N	300	350	450	550	700	900	1100	1250	1450	1600	1800	2000
GRAB ELONGATION T	%	80	80	70	70	60	60	60	60	60	60	60	60
[ASTM D 4632] M	%	50	50	50	50	50	50	50	50	50	50	50	50
TEAR STRENGTH T	N	150	200	250	300	400	500	600	700	750	800	900	950
[ASTM D 4533] M	N	125	150	200	230	300	400	450	550	600	650	750	800
CBR BURST STRENGTH [ASTM D 6241]	KN	0.8	1	1.5	2.5	3	3.5	4	4.5	5	5.5	6	7
PUNCTURE RESISTANCE [ASTM D 4833]	N	180	220	275	310	450	520	600	730	880	990	1050	1150
MULLEN BURST [ASTM D 3786]	MPA	1	1.2	1.3	1.6	2	2.6	3.1	3.8	4.4	5	5.5	6
CONE DROP RESISTANCE [BS EN 918]	MM	34	34	32	29	27	23	20	16	12	11	10	9
HYDRAULIC PROPERTIES
FLOW RATE [ASTM D 4491]	L/S/M2	200	210	180	150	140	130	120	110	110	100	90	80
PERMEABILITY [ASTM 4491]	CM/S	0.46	0.46	0.44	0.41	0.35	0.34	0.3	0.3	0.29	0.29	0.29	0.29
AOS O95 [ASTM D 4751]	MM	0.13	0.12	0.12	0.11	0.11	0.1	0.1	0.09	0.09	0.08	0.07	0.065
PHYSICAL IDENTIFICAITON PROPERTIES
THICKNESS [ASTM D5199]	MM	1.5	1.5	1.8	2.3	2.9	3.2	3.7	4.1	4.3	4.6	4.8	5
APPROX LOADING QTY/40HQ	M2	63600	63600	52800	39600	32400	26400	22800	20400	18000	15600	14400	13200

PioneerTEX Geotextile Silt Bags Features:

**Traditionally settlement methods (such as straw bale structures or settlement ponds/tanks) are

often ineffective, rely on slow water movement, long settlement times, expensive and time consuming

tank maintenance and large works areas.

**Dewatering Bags are an efficient, practical, quick, simple and cost effective alternative solution to

manage this ongoing environmental problem of removing suspended solid pollutants from pumped

water on construction sites.

**Sediment-laden water is simply pumped into the high quality filter bags, which trap the solids inside

and allow filtered water to flow freely out through the geotextile fabric to disperse into the surrounding

ground or another collection point.

**Dewatering Silt Bags can also be used for gravity feed applications such as outfall pipes from site drainage or lagoons.

**The silt filter bags provide a passive non-mechanical solution, without the use of excessive or

specialist machinery (other than possible lifting equipment when full), and do not require a large work area.

**The sediment bags are also light, compact and easy to store, with minimal cleaning up required -

when full just dispose of the bag and replace with another bag.

**The Dewatering Silt Bags detain both oil and sediment, offering a combination of benefits not available

in alternative products. They can also be used to contain contaminated sediment whilst treatments

are applied (such as flocculants or absorbents).

**The standard 1.80 x 1.80m Dewatering bags has the capacity to trap near 1 tonne of silt and cope

with flow rates up to 2,730 l/min, while the larger 3.05 x 4.55m bags can trap over 4 tonnes of silt and cope with flow rates up to 6,818 l/min.
